30
SPECIFICATIONS
J35 BATTERY MANAGEMENT
SYSTEM
J35A J35B-L J35D
Input Voltage Range 240 VAC ± 10% (nominal), 50-60 Hz
Input Surge < 40A (cold start)
Output Current (Load + Battery
Current)
20A 35A
Factory Set Voltage (Float Voltage) 13.65 V +/0.1 V
Output Ripple Voltage < 150 mV
Over Voltage Protection < 18V
Over Current Protection (Load +
Battery Current)
20-25A 35-38A
Battery Current Limit 15A 30A
Low Voltage Disconnect Lead Acid 10.5 ± 0.2V
Low Voltage Disconnect LiFePO4
-
11.5 ± 0.2V
Battery Drain (when in Storage Mode) < 8mA
AC/DC Efficiency > 83 %
Cooling Fan Thermally controlled
Solar Input Current – <20A <27A
Solar Input Voltage – 15-25V
Ambient Temperature 0-50°C
Communication CAN Bus
Dimensions 307mm x 206mm x 68mm
Weight 2 kg
Standards
Safety: AS/NZS 60335.2.29
EMC: AS/NZS CISPR 14.1
Approval: RCM
CONTROLNODE
Input Voltage 8-15 V DC
Battery Drain < 21 mA
Ambient Temperature 0–50ºC
Cable Length 0.5m
