Headlight
Adjusting headlight for
RHD/LHD traffic
This motorcycle's headlight fea-
tures a symmetrical low beam.
No special adjustments or prece-
dures are required prior to oper-
ating the motorcycle in a country
where traffic uses the opposite
side of the road (left-hand drive
to right-hand drive or vice versa).
Headlight range and
spring preload
The headlight range generally
remains constant due to the ad-
justment of the spring preload to
the loading state.
Spring preload adjustment may
only be insufficient when the mo-
torcycle is very heavily loaded.
In this case, the headlight range
must be adjusted to the weight.
If there are questions
whether the headlight
range is correct, consult a
specialized workshop, preferably
an authorized BMW Motorrad
retailer.
Adjusting headlight range
Loosen screws 1 on left and
right.
Adjust headlight by tilting
slightly.
Tighten screws 1 on left and
right.
Seat
Remove seat
Make sure ground is level and
firm and park motorcycle.
Turn storage compartment
lock 1 to right with motorcy-
cle key.
Take off cover 2.
4
38
z Operation

BMW 2012 G 650 GS Sertao Specifications

General

Engine Type	Single-cylinder, four-stroke
Displacement	652 cc
Transmission	5-speed
Fuel System	Electronic fuel injection
Cooling	Liquid-cooled
ABS	Optional
Tires Front	90/90-21
Tires Rear	130/80-17
Power	48 hp (35 kW) at 6, 500 rpm
Torque	60 Nm (44 lb-ft) at 5, 000 rpm
Front Suspension	Telescopic fork
Front Brake	Single disc
Rear Brake	Single disc
Weight	192 kg
Fuel Capacity	14 liters
Seat Height	860 mm
