BMW 2013 S 1000R User Manual

DTC warning lamp flashes
slowly.
Phase 2
Checking system components
capable of diagnosis while
starting off.
DTC warning lamp flashes
slowly.
DTC self-diagnosis
completed
The DTC symbol is no longer
displayed.
Watch all warning and indicator
lamps on the display.
DTC self-diagnosis not
completed
The DTC function is not avail-
able, as the self-diagnosis
function has not been com-
pleted. (To check wheel sen-
sors, motorcycle must reach
a minimum speed with en-
gine running: min 3 mph (min
5 km/h))
If a DTC error is indicated after
the DTC self-diagnosis is com-
pleted:
It remains possible to con-
tinue riding. It must be noted
that the availability of the DTC
function is restricted or it is not
available at all.
Have the malfunction corrected
as soon as possible at an au-
thorized workshop, preferably
an authorized BMW Motorrad
retailer.
Breaking in
Engine
While running in the motorcy-
cle, vary the throttle opening
and engine-speed range fre-
quently; avoid driving for long
periods at a constant speed.
Try to do most of your rid-
ing during this initial period on
twisting, fairly hilly roads, avoid-
ing high-speed main roads and
highways if possible.
Observe the engine run-in
speeds.
Engine run-in speed
<7000 min
-1
(Odometer read-
ing 0...186 miles (0...300 km))
<9000 min
-1
(Odometer
reading 186...621 miles
(300...1000 km))
6
95
z Riding

BMW 2013 S 1000R Specifications

General

Displacement	999 cc
Maximum Torque	112 Nm (83 lb-ft) at 9, 250 rpm
Engine Type	Liquid-cooled 4-stroke in-line four-cylinder engine
Maximum Power	118 kW (160 hp) at 11, 000 rpm
Transmission	6-speed
Frame	Aluminum bridge frame, engine self-supporting
Front Suspension	Upside-down telescopic fork, 46 mm diameter
Rear Suspension	Aluminum 2-sided swing arm
Front Brakes	Dual 320 mm discs, 4-piston calipers
Rear Brakes	Single 220 mm disc, single-piston caliper
ABS	Standard
Curb Weight	207 kg (456 lbs)
Fuel Capacity	17.5 l (4.6 US gal)
