BMW C 650 GT User Manual

Installing side panel ( 122).
Setting the clock ( 56).
Setting the date ( 57).
Fuses
Removing a fuse
Requirement
The fuses are located under the
front right fairing side panel.
ATTENTION
Jumpering of blown fuses
Risk of short-circuit and fire
Never attempt to jumper a
blown fuse.
Always replace a defective fuse
with a new fuse of the same
amperage.
Switch off the ignition.
Remove the side panel
( 121).
Remove faulty fuse from the
fuse box 1 or from the fuse
carrier 2 with the toolkit.
To open the fuse box, press
the locking lever 3 and remove
cover.
NOTICE
If fuse defects recur frequently
have the electric circuits checked
by a specialist workshop,
preferably an authorised
BMW Motorrad dealer.
Install fuse
Replace faulty fuse from the
fuse box with a fuse with the
required current level.
Close cover.
The latch engages with an
audible click.
8
125
z Maintenance
https://www.motorcycle-manual.com/

BMW C 650 GT Specifications

General

Displacement	647 cc
Torque	63 Nm at 6, 000 rpm
Transmission	CVT
Front Suspension	Upside-down fork, Ø 40 mm
ABS	Standard
Front Tire	120/70 ZR15
Rear Tire	160/60 ZR15
Engine Type	4-stroke, 2-cylinder, water-cooled
Power	60 hp (44 kW) at 7, 500 rpm
Rear Suspension	Single swing arm, spring strut
Front Brake	Double disc brake, diameter 270 mm
Rear Brake	Single disc brake, diameter 270 mm
Seat Height	805 mm
Fuel Capacity	15.5 l
Weight	261 kg (unladen weight, road ready)
