E88 Complete Vehicle
Hall Sensor #9
Signals “Convertible Top Compartment Lid Opened” and is located on the rear of the left
top lid hinge bracket shown here.
Hall Sensor #10
Signals when the “Convertible Top Compartment Lid Locked” and is located on the front
of the left hinge behind the top lid locking mechanism.
Note: Sensor located behind
the bracket
9
10
