E88 Complete Vehicle
Hall Sensor #7
Signals “Main Pillar Stowed” and is located on the rear
of the right
side bracket of top linkage/mechanism
(upper most sensor).
Hall Sensor
#6
Signals “Main Pillar Position” and is located on
the rear of the
right side bracket of top link-
age/mechanism (lo
wer most sensor).
7
6
