E85 Information/Communication
- 18 -
If the display is closed manually or electrically while driving, the
display will remain closed at the start of the next trip (last
function memory position). The display must first be raised again
by pressing the switch.
Fig. 15: Positioning the central information display
Index Explanation Index Explanation
1 Mounting trough 4 85 degree position (minimum)
2 Folded down in 0 degree
position
5 100 degree position (normal)
3 ON/OFF fold switch 6 108 degree position (maximum)
KT-10123
