G15�General�Vehicle�Electronics
3.�Control�Units
19
3.4.2.�Rear�radar�sensors�short�range
Rear�radar�sensors�short�range
The�rear�radar�sensors�short�range�are�a�further�development�of�the�lane�change�warning�(SWW)�radar
sensors.�Both�rear�radar�sensors�have�diagnostic�capability.
The�rear�radar�sensor�short�range�left�is�connected�via�a�local�CAN�to�the�rear�radar�sensor�short�range
right.
3.5.�Control�units�on�the�K-CAN4
The�following�control�units�are�connected�to�the�K-CAN4:
• Controller�(CON)
• Integrated�automatic�heating�/�air�conditioning�(IHKA)
• Telematic�Communication�Box�2�(TCB2)
• Head�Unit�High�3�(HU-H3)
• Receiver�Audio�Module�(RAM).
Further�information�on�the�following�control�units�can�be�found�at:
Control�unit Product�information
Controller�(CON) Displays�and�Controls�2018
Head�Unit�High�3�(HU-H3)
Receiver�Audio�Module�(RAM)
Infotainment�2018
