BMW G15 - Partial Network Operation

G15�General�Vehicle�Electronics
4.�Voltage�Supply
41
Safety�battery�terminal
G15�safety�battery�terminal
Index Explanation
1 B+�cable�to�the�starter�motor�and�alternator
2 B+�cable�to�the�jump�start�terminal�point
3 Positive�wire�in�the�power�distribution�box
4 Busbar
5 Safety�battery�terminal�(SBK)
6 Connector,�safety�battery�terminal
7 Busbar
