New Generation N62 Engine Chapter 3 P.80
Course Contents/Background Material
© BMW AG, Service Training
- Oil check valve
Fig. 59: Oil check valves in the cylinder head
Three oil check valves are inserted into each cylinder head from
the outside. This prevents the engine oil from flowing back out of
the cylinder head and the VANOS units.
As the check valves are accessible from the outside, there is no
need to remove the cylinder head when changing the check
valves.
Index Description
1 Oil check valve for VANOS intake
2 Oil check valve for VANOS exhaust
3 Oil check valve for cylinder head oil supply
KT-7706

BMW N62 Series Specifications

General

Configuration	V8
Fuel type	Petrol
Valvetrain	DOHC 4 valves per cylinder
Torque Output	340–490 N⋅m (4.4L), 475-490 Nm (4.8L)
Compression Ratio	10.0:1 (4.4L), 10.5:1 (4.8L)
Engine Block Material	Aluminum
Cylinder Head Material	Aluminum
Cooling system	Water-cooled
Redline	6, 500 rpm
