BMW R 1200 S User Manual

Troubleshooting chart
Engine does not start at all or is difficult to start.
Possible cause Remedy
Kill switch activated Kill switch in operating position
Side stand extended and gear engaged Retract the side stand. ( 72)
Gear engaged and clutch not disengaged Select neutral or pull clutch lever ( 72)
Clutch pulled when ignition was OFF Switch on the ignition, then pull the clutch lever
No fuel in tank Refuelling ( 77)
Battery not adequately charged Charge the battery when connected ( 113)
10
122
z Technical data

BMW R 1200 S Specifications

General

Displacement	1170 cc
Bore x Stroke	101 mm x 73 mm
Max Torque	112 Nm (83 lb-ft) at 6, 800 rpm
Final Drive	Shaft drive
Front Suspension	BMW Motorrad Telelever
Rear Suspension	BMW Motorrad Paralever
Seat Height	830 mm
Engine Type	Air/oil-cooled flat twin (boxer), four-stroke
Max Power	122 hp at 8, 250 rpm
Transmission	6-speed
Front Brakes	Dual 320 mm discs, 4-piston calipers
Rear Brakes	Single 265 mm disc, 2-piston caliper
Fuel Capacity	17 liters
Frame	Three-section frame consisting of front and rear sections, load-bearing engine
