Threaded fasteners
Front wheel Value Valid
Brake caliper to slider tube
M8 x 32 30 Nm
Clamp screw of quick-release
axle
M8 x 35 19 Nm
Quick-release axle in axle holder
M24 x 1.5 50 Nm
Rear wheel Value Valid
Rear wheel to wheel carrier
M10 x 40 x 1.25 Tighten in diagonally opposite
sequence
60 Nm
Locknut for spring basic setting
at top spring retainer
5 Nm with OE Sport
suspension:
10
123
z Technical data

BMW R 1200 S Specifications

General

Displacement	1170 cc
Bore x Stroke	101 mm x 73 mm
Max Torque	112 Nm (83 lb-ft) at 6, 800 rpm
Final Drive	Shaft drive
Front Suspension	BMW Motorrad Telelever
Rear Suspension	BMW Motorrad Paralever
Seat Height	830 mm
Engine Type	Air/oil-cooled flat twin (boxer), four-stroke
Max Power	122 hp at 8, 250 rpm
Transmission	6-speed
Front Brakes	Dual 320 mm discs, 4-piston calipers
Rear Brakes	Single 265 mm disc, 2-piston caliper
Fuel Capacity	17 liters
Frame	Three-section frame consisting of front and rear sections, load-bearing engine
