I.III Explanaon of symbols
In this operang manual, important safety informaon is idened as follows:
Warning – failure to follow the instrucons could result in serious injury or death.
Cauon – failure to follow the instrucons could cause personal injury or damage equipment and/or the surroundings.
This symbol denotes ps and special informaon.
Shows the correct tool and the proper amount of torque for mounng.
In this case a 2.5mm hex wrench should be used to ghten the screw.
Maximum torque for mounng the screw is 1 Nm (newton meter).
Observe these noces at all mes to avoid personal injuries and damage to the product.
I.IV Approved operang condions / locaons
BLOKS. components can be used at temperatures between -10 °C and +60 °C. The IP67 protecon rang means that this component is both
protected against harmful dust as well as protected against immersion in water to a depth of up to 1 meter for up to 30 minutes. Please also
observe the informaon on permissible operang condions contained in the pedelec manufacturer’s operang instrucons. Any limita-
ons regarding permissible operang condions (e.g. maximum climbing capability, maximum permissible height of obstacles, maximum
load, etc.) must be observed when using the pedelec. Observe the safety and hazard informaon provided in the individual chapters of the
user's manual.
I.V Technical data
BLOKS. remote 14d (handlebar control unit)
Remote 14d Rocker switch for + and -, 3 buons, 22.2mm inner diameter, hard-wired
Display type LCD (Liquid Crystal Display)
Color depicon Monochrome
Display diagonal 1.4 inch / 35.4mm
Dimensions (W x L x H) 22mm x 46mm x 51mm
Display screen Hard-coated PMMA (PolyMethyl MethAcrylate) acrylic glass lens
Protecon rang IP67
Weight with cable 58 g
1. What is the BLOKS. remote 14d?
The BLOKS. remote 14d is a control unit with an integrated LCD display mounted on the handlebars. Since all important informaon is
shown on the high-contrast, 1.4-inch monochrome LCD, a larger display mounted in the middle of the handlebars is not necessary – the
remote 14d is a self-contained system.
