1 Introduction
This manual is a reference designed to familiarize you with the BNC Model 577 Series Pulse Generator and is
arranged so that you can easily find the information you’re looking for. Generally, each topic has its own section
and no section assumes that you’ve read anything else in the manual.
Technical specifications including electrical ratings and weight are included within the manual. See the Table of
Contents to locate the specifications and other product information. The following classifications are standard
across all BNC Test and Measurement products.
● Indoor use only
● Ordinary Protection: This product is NOT protected against the harmful ingress of moisture.
● Class 1 Equipment (grounded type)
● Main supply voltage fluctuations are not to exceed +/-10% of the nominal supply voltage.
● Pollution Degree II
● Installation (overvoltage) Category II for transient overvoltage events
● Maximum Relative Humidity: 0-80% RH, non-condensing
● Operating temperature range of 0
o
C to 40
o
C
● Storage and transportation temperature of -40
o
C to 70
o
C
● Maximum altitude: 2000 m (6562 ft.)
● This equipment is suitable for continuous operation.
● Cleaning Instructions: Light dusting with cloth damp with water and/or usage of compressed air is all that
is needed.
1.1 Technical Support
For questions or comments about operating the Model 577 our technical staff can be reached via one of the
following methods:
● Phone: +1.415.453.9955
● Fax: +1.415.453.9956
● Email: support@berkeleynucleonics.com (Device) or info@berkeleynucleonics.com (Manual)
● Internet: www.berkeleynucleonics.com
1.2 Warranty
In addition to a 30-day money back guarantee, the model 577 has a two-year limited warranty from the date of
delivery. This warranty covers defects in materials and workmanship. If repairs are required during the warranty
period, contact the factory for component replacement or shipping instructions. Include the serial number of the
instrument. This warranty is void if the unit is repaired or altered by others than those authorized by Berkeley
Nucleonics Corporation.
1.3 Package Contents
The box you receive should contain the following:
• Model 577 Digital Delay / Pulse Generator
• AC Power Cord
• USB or Compact Disk that contains:
Operating or User Manual (this document)
Software Drivers
Communication Software
Contact BNC support by phone or email if any parts are missing.
Berkeley Nucleonics Corporation
info@berkeleynucleonics.com | www.berkeleynucleonics.com
2955 Kerner Blvd, San Rafael, CA 94901 | 800-234-7858
