8
QUICKCAT
MOWERS
®
LUBRICATION
Every 50 hours of operation, lubricate the following points (1-3) with grease:
1. Deck lift pivots (4 points)
2. Pull arm pivots (4 points)
3. Deck idler pivot (1 point)
Every 500 hours or once a year:
4. Caster wheel pivots (2 points)
NOTE ON BLADE SPINDLES - The blade spindles on these machines use a superior sealed bearing that
does not require re-lubrication.
MAINTENANCE
1
1
2
