BOC Edwards 412-J - Page 24

M OD EL 2 12J M ICROV AC PUM P M OD EL 2 12J M ICROV AC PUM P
LOT NO. SC-7 870 3 (7-99 ) AND FUTURELOT NO. SC-7 870 3 (7-99 ) AND FUTURE
SY MSY M PA RT N O.PART NO. DESCRIPTIONDESCRIPTION
REF. DWG/ REF. DWG/
COM P. LIT.COM P. LIT.
QTYQTY UMU M RSPRSP
1
606-727-001
PUM P HOUSING
1
EA
2
085-048-064
PLUG EXPANSION
4
EA
4
3 423-860-001 REDUCING BUSHING 1 EA
4 008-002-034 PIN DOWEL 4 EA
5
026-010-036
PLUG 1/8 NPT
1
EA
6
026-010-037
PLUG 1/4 NPT
1
EA
7
026-010-039
PLUG 1/2 NPT
4
EA
8
026-010-040
PLUG 3/4 NPT
3
EA
9
085-050-765
STREET ELBOW 1/2 NPT
3
EA
10
085-050-738
BALL VALVE
1
EA
11
243-926-002
GASKET VALVE DECK
2
EA
4
12
263-840-004
VALVE DECK
2
EA
4
13
085-050-414
SCREW SOCKET HEAD M 8 X 1.25 X 30 M M LG.
8
EA
14
264-504-003
OIL BAFFLE
1
EA
15
085-041-960
SCREW HEX HEAD M 8 X 1.25 X 20 MM LG.
6
EA
16
085-050-358
LOCKWASHER INTERNAL TOOTH
6
EA
17
246-763-002
OIL BAFFLE GASKET
1
EA
18
606-753-002
RESERVOIR OIL
1
EA
19
085-050-761
O' RING 18
1
EA
4
20
085-050-356
SCREW HEX HEAD M 10 X 1.5 X 25 MM LG.
10
EA
21
085-041-950
LOCKWASHER SOCKET HEAD
10
EA
22
085-050-756
EYEBOLT
2
EA
23
085-041-954
NUT M 12 X 1.75 M M
2
EA
24
085-036-021
PLUG 1 NPT
1
EA
25
606-180-003
M OTOR PLATFORM BLOCK
1
EA
26
085-050-815
SCREW SOCKET HEAD M 12 X 1.75 X 70 MM LG.
2
EA
27
085-050-816
LOCKWASHER SPLIT SOCKET HEAD
2
EA
28
606-755-001
M OTOR PLATFORM
1
EA
29
085-050-760
JACK SCREW M12 X 1.75 X 140 M M LG.
2
EA
30
085-050-757
WASHER SPHERICAL MALE HALF 1/2 BOLT SIZE (M 12)
4
EA
31
085-041-954
NUT M 12 X 1.75 M M
4
EA
32
085-041-960
SCREW HEX HEAD M 8 X 1.25 X 20 MM LG.
4
EA
33
085-050-358
LOCKWASHER INTERNAL TOOTH
4
EA
RSP = RECOM M ENDED SPA RE PARTRSP = RECOM M END ED SPARE PART
UM = UNIT OF M EASU REUM = UNIT OF M EASURE
Page 3Page 3
7-7-9 97-7-99
REVISION 1.2REVISION 1.2
