M OD EL 2 12J M ICROV AC PUM P M OD EL 2 12J M ICROV AC PUM P
LOT NO. SC-7 870 3 (7-99 ) AND FUTURELOT NO. SC-7 870 3 (7-99 ) AND FUTURE
SY MSY M PA RT N O.PART NO. DESCRIPTIONDESCRIPTION
REF. DWG/ REF. DWG/
COM P. LIT.COM P. LIT.
QTYQTY UMU M RSPRSP
100
085-041-955
WASHER PLAIN (M 12)
1
EA
101
085-041-959
SCREW HEX HEAD M 12 X 1.75 X 20 MM LG.
1
EA
606-766-001
BELT GUARD ASSEM BLY CONSISTING OF:
1
EA
102
BELT GUARD FRONT
1
EA
103
BELT GUARD BACK
1
EA
104
WASHER PLAIN (M 8)
6
EA
105
NUT M 8 X 1.25 M M
6
EA
606-767-001
FLYWHEEL GUARD ASSEM BLY CONSISTING OF:
1
EA
106
FLYWHEEL GUARD BACK
1
EA
107
FLYWHEEL GUARD FRONT
1
EA
108
WASHER PLAIN (M 8)
4
EA
109 NUT M 8 X 1.25 M M 4 EA
110
085-035-996
DOWEL PIN
2
EA
111
085-050-413
SCREW SOCKET HEAD M 8 X 1.25 X 20 M M LG.
4
EA
RSP = RECOM M ENDED SPA RE PARTRSP = RECOM M END ED SPARE PART
UM = UNIT OF M EASU REUM = UNIT OF M EASURE
Page 6Page 6
7-7-9 97-7-99
REVISION 1.2REVISION 1.2
