BOC Edwards 412-J - Page 30

Model 412-J14 Microvac Pump
ITEM NO.
CODE NO. DESCRIPTION QTY. REF. DRAWING
1 606-191-003 PUMP HOUSING 412J 1 D-606-191-003F
2 607-059-003 RESERVOIR,MACHINING 1 D-607-059-003
3 605-432-005 COVER 1 D-605-432-005A
4 605-988-004 SIDE COVER, DRIVE END 1 D-605-988-004E
5 605-988-003 SIDE COVER,DEAD END 1 D-605-988-003E
6 243-595-011 PISTON & SLIDE 412/212 2 D243-595-011G
7 252-459-001 ECCENTRIC,SOLID 1 C252-459-001X
8 278-575-001 ECCENTRIC,HOLLOW 412/212 1 C-278-575-001M
9 262-315-005 CAP,DRIVE END 1 C262-315-005F
10 264-789-003 CAP,DEAD END 1 C-264-789-003B
11 607-417-001 POPPET VALVE ASSEMBLY 4 B-607-417-001
12 264-785-002 RING, BEARING 412 W/ PIN 1 C-264-785-002P
13 085-033-232 BRG RLLR SPH 2.1654 IDX3.9370 1
14 262-992-005 SHAFT 1 D262-992-005-J
15 408-324-005 SQUARE KEY 2 A-408-324-005B
16 264-524-001 WOODRUFF KEY 1 A-264-524-001D
17 269-256-005 OIL SEPARATOR 1 D-269-256-005B
18 262-318-003 RING 2 A-262-318-003A
19 297-857-004 HINGE BAR 4 B-297-857-004E
20 268-788-001 SPACER 1 A-268-788-001D
21 606-180-001 BLOCK, HINGE 1 A-606-180-001A
22 606-279-002 OIL MANIFOLD 1 C-606-279-002
23 606-130-001 AXLE 1 A-606-130-001
24 605-618-002 STUD 2 A-605-618-002A
25 606-003-001 RETAINER 2 A-606-003-001B
26 606-002-001 STEM VALVE 2 A-606-002-001D
27 606-127-001 PADDLE 1 B-606-127-001B
28 605-770-003 RETAINER, LENS 2 A-605-770-003B
29 606-309-003 BELT GUARD ASSY. 1 A-606-309-003
30 606-272-004 BRACKET,BOTTOM 1 B-606-272-004
31 408-306-008 BRACKET,MIDDLE 1 B-408-306-008
32 085-019-755 O RING 4-7/8 IDX5-1/8 OD.139CS 2 *
33 085-029-600 SEAL ROTARY OIL 1 A-085-029-600A*
34 085-041-609 O RING 5/8 ID X .139 CS VITON 4
35 085-050-120 SEAL 1/4 ID X 5/8 OD X 3/16 TK 2
36 085-050-192 O-RING 15/16 ID X .139W (-213) 2
37 085-050-115 O-RING 1/2 ID X .139 W (-206) 2
38 243-926-002 GASKET,VALVE PLATE 4 A-243-926-002A
39 085-050-119 O-RING 28 1/4 ID X .210 C/S 1
40 085-050-118 O-RING 23 ID X .210 C/S 1
41 085-050-116 O-RING 1 3/4 ID X .139 C/S 2
42 269-037-001 GASKET,OIL SEPARATOR 1 B-269-037-001
43 085-019-757 BALL BEARING 2
44 085-050-117 O-RING 13 1/2 ID X.139 C/S 2
