Table of content
1. NTRODUCTION 3
2. ELECTRICAL AND MECHANICAL SAFETY STANDARDS 3
3. UNPACKING 3
4. REQUIRED TOOLING 4
5. INSTALLING 8000 SCOREBOARDS 4
5.1 Attachment to wall bracket (Ref.: standard scoreboard reference) 4
5.2 Mounting on existing BODET wall bracket (ref: 916 427) 6
5.3 Suspended mount (ref: 916 426) 7
5.4 Mounting from the back (Ref.: standard scoreboard reference) 7
5.5 Electrical connections 9
5.5.1. HF installation 9
5.5.2. Wired installation 9
6. INSTALLING ADDITIONAL MODULES 12
7. INDIVIDUAL FOUL PANEL INSTALLATION 16
7.1 Opening an F6 individual foul panel 16
8. INSTALLATION CONFIGURATIONS 19
