Body Champ BCB580 - Part Listing

BCB580 Page 5
Part Listing
The following parts list describes all of the parts illustrated on the exploded diagram on the following page.
PLEASE NOTE : Not all of the parts and hardware you see here will be used while you are assembling the unit because
some of these items are already pre-installed. Please use this page only as a reference guide for parts and hardware.
# Description # Description
01 Front Upright
02 Leg Developer
03 Main Frame
04 Rear Cross Tube
05 Rear Upright
06 Reinforcement Plate
07 Backrest Adjustment Tube
08 Buttery
09
Foam Roller Tube
10 Arm Curl Frame
11 Weight Plate Bar
12 Foam Roller Tube Hex Bolt (M10x140 mm)
13 Supporting Tube
14 Backrest Cushion Tube
15 Left Weight Rest
16 Right Weight Rest
17 Arm Cushion
18 Seat Cushion
19 Backrest Cushion
20 Foam Roller
21 Round End Cap (Φ19 mm)
22 Round End Cap (Φ25 mm)
23 Square End Cap (口50 mm)
24 Square End Cap (口45 mm)
25 Square End Cap (口38 mm)
26 Square End Cap (口33.4 mm)
27 Square End Cap (口25 mm)
28 Square End Cap (口20 mm)
29 Sleeve (口45x38 mm)
30 Bumper (Φ25 mm)
31 Bumper (Φ25x50 mm)
32 Knob Bolt (M10x50 mm)
33 Knob (M10)
34 Quick Clip (Φ25 mm)
35 Hex Bolt (M10x65 mm)
36
37 Hex Bolt (M10x160 mm)
38 Hex Bolt(M10x20 mm)
39 Carriage Bolt (M8x45 mm)
40 Hex Bolt (M8x55 mm)
41 Hex Bolt (M8x40 mm)
42 Hex Bolt (M8x35 mm)
43 Hex Bolt (M8x15 mm)
44 Washer (M8)
45 Washer (M10)
46 Nylon Nut (M8)
47 Nylon Nut (M10)
48 Screw (M4x10 mm)
