Body Champ PT620 - Hardware and Tool List

PT620 / VKR1808 Page
4
Hardware and Tool List
Bolts
Washers
Nuts
#13. Bolt (M8x65 mm) [4 pieces] #16. Carriage Bolt (M10x65 mm) [8 pieces]
#19. Bolt (M8x70 mm) [12 pieces] #25. Bolt (M8x75 mm) [4 pieces]
#28. Screw (M8x35 mm) [2 pieces]
#14. Washer (M8) [10 pieces]
#15. Lock Nut (M8) [14 pieces] #18. Lock Nut (M10) [8 pieces]
#17. Washer (M10) [8 pieces] #20. Curved Washer (M8) [26 pieces]
#30. Bolt (M8x20 mm) [2 pieces]
