BodyCraft XFT - Product Assembly - Step 3; Insert and Align Main Upright Frame; Secure Main Upright Frame

8
ProductAssembly STEP
1.Pleaseconfirmthatthe2
nd
PackingBolt(A)and
Washer(B)havebeenremovedfromthebottom
oftheMainUprightFrame(5).SeeFig.1.
2.InserttheMainUprightFrame(5)totheBase
Frame(1)asshowninFig.1andFig.2.SLIDE
theMainUprightFrame(5)fromthesideuntilthe
mountingholesalign.SeeFig.2
3.Secureusingfour3/8”X1”SunkenHeadBolts
(100),eight3/8”Washers(118)andfour3/8”Nylon
Nuts(131)asshowninFig.1.
4.RotatetheSteelPlates(44)backintotheiroriginal
positionsandsecurewiththeeightpreviously
removed5/16”X1/2”SunkenHeadBolts(122).
SeeFig3.
15
44
122
122
Fig.1 Fig.2
SLIDE
5
1
5
1
A
B
118
118
131
100
118
100
118
REMOVE
Fig.3
Toeasetheassemblyprocess,
donottightenboltsuntiltoldtodoso.
3
