BodyCraft XFT - Product Assembly - Step 4; Attach Top Frame to Uprights; Loosely Secure Top Frame; Attach Pulleys to Top Frame

9
ProductAssembly STEP
1.AttachtheTopFrame(13)totheMainUpright
Frames(5)byfirstroutingeachoftheCounter
WeightCables(131)upthroughtheouterpulley
holdersasshowninFig.1.
2.LooselysecurethetheTopFrame(13)usingeight
3/8”X1”HexThreadedBolts(100),sixteen3/8”
Washers(118)andfour3/8”NylonNuts(131).
SeeFig.1
3.Attachtwo90mmPulleys(52)totheTopFrame
(13)byfirstroutingthecableovereachpulley.
Securethepulleysusingtwo3/8”X1-3/4”Hex
Bolts(98)andtwo3/8”NylonNuts(131).When
completed,theCableBoltportionshouldbebelow
theTopFrameasshowninFig.2.
Fig.1 Fig.2
5
5
100
100
118
100
118
118
118
131
131
118
118
100
118
131
131
118
13
98
52
52
54
54
98
131
131
13
Toeasetheassemblyprocess,
donottightenboltsuntiltoldtodoso.
4
