BodyCraft XFT - Product Assembly - Step 8; Attach Top Plate to Selector Stem; Install Guide Rod Holders and Rods; Load Weight Plates onto Guide Rods

14
ProductAssembly STEP
1.AssemblytheTopPlate(38)tothetheSelectorStem(40)usingoneTopPlateBolt
(103).TIGHTENtheTopPlateBolt(103)atthistime.
2.InstalleachofthePlasticGuideRodHolders(72)intotheBaseFrame(1),and
inserttheGuideRods(4).Ifyouhave19piecesofWeightPlates(39)discardthe
StackSpacers(26),andrefertoFigure1fortheproperconfiguration.Ifyouhave
14piecesofWeightPlates(39),thenrefertoFigure2forthecorrectconfiguration.
NOTE:WheninstallingtheWeightPlates(39),makecertainthateachplateis
orientedwithselectorholeopeningonthebottomandfacingforward.
3.Withtheguiderodsangledslightlyforward(asshowninatthebottomleft).Slide
theWeightPlates(39)oneatatimeontotheGuideRods(4),makingsureto
orienttheselectorholesfacethefrontasshown.
4.SlidetheTopPlate/SelectorStemAssemblyontotheGuideRods,makingsure
theSelectorRod(40)goesthroughthecenterholesoftheWeightPlates(39).
5.AttachGuideRodHolder(17)ontotheGuideRods(4)andreturntheguiderodsto
theuprightposition.ThensecuretheGuideRodHolderwithtwo5/16”X5/8”
RoundScrews(106).Tightenthetwo5/16”X1/4”InnerHexScrews(116)tothe
GuideRods(4).
Ifyouhave19WeightPlates,DONOTinstall
thetwoStackSpacers(24),Seefigures12.
8
