Assembly Instructions
Page 12
STEP 5
38
17
10
1.Mount Two End Caps (#17) to Rear Upright (#10).
2.Put two Rubber Bumpers(#38) on the sleeves of Rear Upright (#10).
19
Step 5: Assembly of the Rear Upright
1. Attach two end caps (17) to the rear upright (10).
2. Attach two rubber bumpers (38) to the sleeves of the rear upright (10).
