FXB30 FOLDABLE EXERCISE BIKE
4 ASSEMBLY
4.2 Package contents
The package contains the parts represented in the illustration. If one of the illustrated parts is
missing, please contact your contract partner.
No.4
Cambered Washer (D8×1.5×ø20) x 6pcs
No.16
Flat Washer (D8×ø25×2) x 2pcs
No.2
Screw (M5×10mm) x 4pcs
No.5
Spring Washer (D8) x 4pcs
No.17
Flat Washer (D8) x 3pcs
No.13
Bolt (M8×45×15) x 4pcs
No.10
Nylon Nut (M8) x 5pcs
No.20
Domed Nut (M8) x 4pcs
No.15
Bolt (M8×40mm) x 2pcs
No.3
Bolt (M8x40x15) x 2pcs
No.19L
Nylon nut (Left side) x 1pc
No.8
Knob (M16×1.5×22) x 1pc
No.19R
Nylon nut (Right side) x 1pc
