4.3 Assembly Step
Before assembly, take a close look at the individual assembly steps shown and carry out the
assembly in the order given.
NOTICE
First loosely screw all parts together and check that they t properly. Tighten the screws using
the tool only when you are instructed to do so.
Step 1:
1. Remove the Main Frame (7) and Plug (24).
2. Open the Main Frame (7) then inset the Plug (24) into the hole .
