BODYMAX FXB30 - Assembly Step 2

12
FXB30 FOLDABLE EXERCISE BIKE
7
20
20
22
4
4
21
4.3 Assembly Step
Step 2:
Inset the Rear Buttom Tube (21) and the Front buttom tube into the corresponding hole of Main
Frame (7) then lock Domed Nut (20) in Main Frame (7) by using Cambered Washer (4).
