BODYMAX FXB30 - Assembly Step 3

13
10
17
11
8
9
4.3 Assembly Step
Step 3:
Lock the Saddle (9) in the Saddle Tube (11) by using Flat Washer (17)and Nylon Nut (11) then inset
the Saddle Tube (11)into Main Frame (7) and lock it use Knob (8). The Knob (8) towards the left if
need adjust the height .
4 ASSEMBLY
