11
4 ASSEMBLY
In order to make the assembly of the equipment easier, we recommend that you do not
initially fully tighten the screws and bolts. However, you should make sure that all screws
and bolts are rmly tightened after assembly.
4.1 Package contents
The package contains the parts represented in the illustration. If one of the illustrated parts is
missing, please contact your contract partner.
NO.55
Pan Head Screw (M8×55) × 2pcs
NO.64
Flat Washer (D8×ø16×T1.5) × 2pcs
NO.67
Cap Nut (M8) × 2pcs
NO.53
Hex Bolt (M12×145) × 2pcs
Tools
No.50
Alien Wrench (S5) × 1pc
No.51
Spanner (S10/13/17/19) × 1pc
