RM40 Rowing Machine
9.3 Parts list
No. Description Qty. No. Description Qty.
1
Main Frame 1 43 Small Bushing 1
2
Rear Stabilizer 1 44 Big Bushing 1
3
Watch Stand Assembly 1 45 Handle Grip 2
4
Magnetic Assembly 1 46 T-knob 1
5
Front Stabilizer 1 47 Rubber Pad 2
6
Hand Bar Tube 1 48 Alloy Bushing 2
7
Aluminum Track 1 49 Console Limit 1
8
Seat Plate 1 50 Allen Wrench (S5) 1
9
Console Plate 1 51 Spanner (S=10/13/17/19) 1
10
Reinforcement Plate 2 52 Spring 1
11
Pedel Axle 1 53 Hex bolt (M12×160) 2
12
Magnetic Wheel 1 54 Allen Screw (M8×20) 9
13
Spiral Spring 1 55 Pan Head Screw (M8×55/ 8×8 /15) 2
14
Tension Knob 1 56 Allen Screw (M8×32) 10
15
Rear Cover(L) 1 57 Allen Screw (M8×115) 1
16
Rear Cover(R) 1 58 Allen Screw (M8×80) 1
17
Front Cover(L) 1 59 Allen Screw (M8×70) 1
18
Front Cover(R) 1 60 Cross Bolt (M5×12) 4
19
Left Pedal 1 61 Allen Screw (M6×15) 4
20
Right Pedal 1 62 Cross Bolt (M5×10) 4
21
Rear Endcap 2 63 Spring Washer (8) 8
22
Limit Cushion 4 64 Flat Washer (8×16×1.5) 17
23
Tube Endcap 1 65 Hex Nut (M8) 1
24
Seat 1 66 Lock Nut (M8) 7
25
Pedal Velcro 2 67 Cap Nut (M8) 3
26
Bottle Cage 1 68 Flat Washer (8×16×0.8) 5
27
Front Endcap 2 69 Lock Nut (M5) 2
28
Seat Pulley 4 70 Flat Washer (6×12×1.5) 4
29
Wire Hole Plug 2 71 Cross Bolt (ST4.2×25) 6
30
Sensor 2 72 Cross Bolt (ST4.2×12) 4
31
Console 1 73 Cross Bolt (ST4.2×19) 12
32
Handbar Cover (Upper) 1 74 Cross Bolt ( ST4.2×20) 5
33
Handbar Cover (Lower) 1 75 Round Hole Fixing Plate 1
34
Ribbon Pulley 1 76 Hex Nut (M10) 4
35
Bearing Holder 2 77 Hex Nut w Teeth (M10) 4
36
Computer Cover 1 78 Panhead Self-taping Screw (ST4.2×20) 2
37
Computer Board 1 79 Foot Pad 2
38
Hand Grip Holder 1 80 Sunk Self-taping Screw (ST4.2×25) 2
39
Rotating Wheel Support 1 81 Front Pad (L) 1
40
Left Corner 1 82 Front Pad (R) 1
41
Right Corner 1 83 Hex Bolt (M8×30) 1
42
V-Belt 1 84 Outer Bushing 2
