BODYTONE EVOR4 - Parts List

PARTS LIST
NO.
Description
QTY
NO.
Description
QTY
1
Mainframe
1
26
Square end cap
2
2
Handlebar post
1
27
Round cap 1
2
3
Small handle
1
28
Round cap 2
2
4
Saddle frame
1
29
Handlebar foam grip 1
2
5
Front stabilizer
1
30
Handlebar foam grip 2
2
6
Rear stabilizer
1
31L/R
Pedal
1/1
7
Backrest frame seat
1
32
Rear stabilizer end cap
2
8
Adjustable handle
1
33
Adjustable leveler
1
9
Square neck pan head bolt
M8X74 M8X74
2
34
Saddle
1
10
Square neck pan head bolt
M8X93
2
35
Backrest
1
11
Inner hex pan head bolt M8X16
11
36
End cap
1
12
Hex pan head bolt M8X12
16
37
Cross pan head self-drilling screw
39
13
Inner hex pan head bolt M6X40
4
38
Sensor wire
1
14
Inner hex cylinder head M6X10
4
39
Nut M10
1
15
Spring washer D8
12
40
Arc washer
4
16
Inner hex pan head bolt M8XL93
2
41
Console
1
17
Cap nut M8
4
42
Cross pan head screw
4
18
Flat washer D8X1.5
19
43
Sensor trunk wire
1
19
Flat washer D6XD16X1.2
4
44
Pulse wire
2
20
Curve washer D8XD25X1.5, R30
6
45
Pulse trunk wire 1
2
21
Eccentric shaft
1
46
Pulse trunk wire 2
2
22
Handle for moving
1
47
Handle grip
1
23L/R
R
Crank
1/1
48
End cap
1
24L/R
Handlebar cover
1/1
49
Inner hex pan head bolt M8X20
6
25
Front stabilizer end cap
2
50
Motor
1
51
Tension wire
1
76
Clamping eccentric wheel
1
52L/RR
RR
Cover
1/1
77
Upper pressure block
1
53
Phillips tapping screw ST4.2x10
4
78
Hex nut M6
1
54
Crank shield cover
2
79
Chain bolt
1
55
Crank shield
2
80
Allen bolt M8x20
4
