BODYTONE EVOT3 - 页面 22

─ 22 ─
Main frame
Exploded View and Parts List
Item No.
Grade No. Part No. Description QTY
46 6.1.46 L1900JDP-SMY-XHB-9 Console Wire Down 1
47 6.1.47 LD2000 Protective Sleeve 1
48 6.1.48 L100AMP175022-1-L-14 cable 2
49 6.1.49 L100AMP175022-1-N-14 cable 2
50 6.1.50 L350AMP175022-JD-1 cable 1
51 6.1.51 L400AMP175022-1-L-14 cable 2
52 6.1.52 L400AMP175022-1-N-14 cable 1
53 6.1.53 AC32705800 Quick nut 5
54 6.1.54 CNLM6*40DHS20
Hexagon socket countersunk head cap head screw M6*40
12
55 6.1.55 CNLM8*35DHS20NL
Hexagon socket countersunk head cap head screw M8*35
4
56 6.1.56 CNLM8*45DN20
Hexagon socket countersunk head cap head screw M8*45
4
57 6.1.57 DQ10DHS2A Washer Φ10 2
58 6.1.58 DQ5DHS2 Washer Φ5 3
59 6.1.59 DQ8DHS2A Washer Φ11 5
60 6.1.60 DQXK8.4 U-shaped line card 3
61 6.1.61 GB6560M4*8DSG Phillip Screw M4*8 4
62 6.1.62 GB6177M16DS2 Hex flange surface nut 2
63 6.1.63 GB17880.5M8*16.5DCS Flat head hexagon riveted nuts M8 4
64 6.1.64 GB17880.3M5*13DS17 Countersunk head hexagon riveted nuts M6 24
66 6.1.66 GB41M4DS2 Nut M4 2
67 6.1.67 GB5780M10*50DS20 Hex Head Bolt M10*50 1
68 6.1.68 GB6560M4*12DS Phillip Screw M4*8 2
69 6.1.69 GB70M10*55*55DHS2 Socket Head Cap Screw M10*50 1
70 6.1.70 GB70M10*80*80DHS2 Socket Head Cap Screw M10*80 2
71 6.1.71 GB70M8*95DHS20 Socket Head Cap Screw M6*95 1
72 6.1.72 STDP6800 Locknut M8 13
73 6.1.73 GB818M5*15DS2 Phillip Screw M5*20 22
74 6.1.74 GB818M6*16DHS20 Phillip Screw M5*20 5
75 6.1.75 GB819M4*12DS2 Philips countersunk head screwM4*12 2
76 6.1.76 GB845ST4.2*16DS Phillip Screw ST4.2*16 4
77 6.1.77 GB862.24DS12 Serrated lock washers Φ4 4
78 6.1.78 GB9074ST4.2*16DHS Philips big pan head self-drilling screw 25
79 6.1.79 NM10DHS2 Locknut M8 1
80 6.1.80 SD2.5*75 Band Cable 4
81 6.1.81 SD4*150 Band Cable 4
82 6.1.82 SDZ21 STRAP BASE 4
83 6.1.83 DQXX0110.4 R type clamp 3
84 6.1.84 DQXX018.4 R type clamp 3
