Product description
BOGE Operating instructions for S 40-2...S 341 / SF 40-2...SF 220 series screw compressors
Technical data
Technical data for S 40-2 to S 100-2, part 1
1
) Standard equipment. Mains voltages and frequencies are specified on a plate in the switch cabinet.
2
) Only for 460 V / 60 Hz. The fuse values change in the case of other mains voltages and frequencies.
2.1
Water cooling
Air cooling
Type S 40-2 S 50-2 S 60-2 S 61-2 S 75-2 S 100-2
Dimensions
– Height (silenced) [inch] 57 57 57 57 57 57
– Height (super silenced) [inch] 77 77 77 77 77 77
– Depth [inch] 64 64 64 79 79 79
– Width (silenced / super silenced) [inch] 38 38 38 42 42 42
Weight
– silenced [lbs.] 1790 1830 1855 2570 2680 3135
– super silenced [lbs.] 1860 1900 1915 2670 2790 3245
Max. sound pressure level [±3 dB(A)]
accord. to DIN 45635, part 13 76/71 78/72 78/73 79/73 79/73 80/73
– silenced / super silenced [dB(A)]
Measuring surface dimension
15/16 15/16 15/16 16/17 16/17 16/17
– silenced / super silenced [dB(A)]
Sound capacity level
91/87 93/88 93/98 95/90 95/90 96/90
– silenced / super silenced [dB(A)]
Max. sound pressure level [±3 dB(A)]
accord. to DIN 45635, part 13 75/70 77/71 77/72 78/72 78/72 79/72
– silenced / super silenced [dB(A)]
Measuring surface dimension
15/16 15/16 15/16 16/17 16/17 16/17
– silenced / super silenced [dB(A)]
Sound pressure capacity
90/86 92/87 92/88 94/89 94/89 95/89
– silenced / super silenced [dB(A)]
Compressor
max. final compression temperature [°F] + 230 + 230 + 230 + 230 + 230 + 230
Volume flow according to ISO 1217 Part C
– p
max
= 100 psig [cfm] 195.3 234.8 257.6 285.5 345.9 448.6
– p
max
= 115 psig [cfm] 182.6 224.2 247.2 271.9 329.4 427.3
– p
max
= 125 psig [cfm] 182.6 224.2 247.2 271.9 329.4 427.3
– p
max
= 150 psig [cfm] 163.5 204.1 223.9 244.4 293.1 370.8
– p
max
= 190 psig [cfm] 134.9 174.8 189.3 207.3 251.1 324.9
Drive motor
Rated power [hp] 40 50 60 60 75 100
Rated speed
– 60 Hz [min
-1
] 3600 3600 3600 3600 3600 3600
Protection type TEFC TEFC TEFC TEFC TEFC TEFC
ISO class F F F F F F
Electrical connection
Mains voltage
1
) [V]
200/208/230 230 230 230 230 230
460/575 460/575 460/575 460/575 460/575 460/575
Frequency
1
) [Hz] 60 60 60 60 60 60
Recommended fuse protection
2
) [A]
150/150/125 175/70 175/90 175/90 225/125 300/150
60/50 60 70 70 90 125
