Boge SF 40-2 User Manual

Produkt.pm6.5 - USA
Page 2.3
Product description
BOGE Operating instructions for S 40-2...S 341 / SF 40-2...SF 220 series screw compressors
Type S 40-2 S 50-2 S 60-2 S 61-2 S 75-2 S 100-2
Oil filling quantity
Oil receiver volume [gallon] 11 11 11 17 17 17
Total oil filling quantity [gallon] 6 6 6 10 10 10
Oil topping up quantity
between min. + max. [gallon] 1.5 1.5 1.5 2 2 2
Intake air temperature
– min. [°F] + 41 + 41 + 41 + 41 + 41 + 41
– max. [°F] + 113 + 113 + 113 + 113 + 113 + 104
Cooling air requirement
– free-standing installation [cfm] 6600 7700 7700 7700 9400 10800
– with supply and exhaust [cfm] 3300 3800 3800 3800 4700 5400
– (air duct)
– free ventilator pressure [inch/H
2
O] 0.24 0.24 0.24 0.24 0.24 0.24
Cooling air requirement
– free-standing installation [cfm] 1200 1200 1200 1200 1200 1200
– with supply and exhaust [cfm] 600 600 600 600 600 600
Required cooling water quantity
– delta t = 15 K [cfm] 0.958 1.182 1.440 1.440 1.764 2.404
– delta t = 30 K [cfm] 0.479 0.591 0.720 0.720 0.882 1.202
Max. cooling water quantity [cfm] 2.05 2.1 2.05 2.05 2.5 2.5
Cooling water inlet temperature
– min. [°F] + 41 + 41 + 41 + 41 + 41 + 41
– max. [°F] + 86 + 86 + 86 + 86 + 86 + 86
Cooling water outlet temperature
– max. [°F] + 113 + 113 + 113 + 113 + 113 + 113
Cooling water pressure
– min. [psig] 30 30 30 30 30 30
– max. [psig] 146 146 146 146 146 146
Operating pressure switch
1
)
(factory settings)
– p
max
= 100 psig: Switch-off press. p
max
[psig] 100 100 100 100 100 100
Switch-on press. p
min
[psig] 87 87 87 87 87 87
– p
max
= 115 psig: Switch-off press. p
max
[psig] 115 115 115 115 115 115
Switch-on press. p
min
[psig] 100 100 100 100 100 100
– p
max
= 125 psig: Switch-off press. p
max
[psig] 125 125 125 125 125 125
Switch-on press. p
min
[psig] 110 110 110 110 110 110
– p
max
= 150 psig: Switch-off press. p
max
[psig] 150 150 150 150 150 150
Switch-on press. p
min
[psig] 130 130 130 130 130 130
– p
max
= 190 psig: Switch-off press. p
max
[psig] 190 190 190 190 190 190
Switch-on press. p
min
[psig] 174 174 174 174 174 174
Safety valve
Activation pressure at:
– p
max
= 100 psig [psig] 160 160 160 160 160 160
– p
max
= 115 psig [psig] 160 160 160 160 160 160
– p
max
= 150 psig [psig] 160 160 160 160 160 160
– p
max
= 190 psig [psig] 203 203 203 203 203 203
Air cooling
1
) Compressors for other operating pressures P
min
= P
max
minus (–) 14.5 psig.
Technical data for S 40-2 to S 100-2, part 2
2.1 Technical data
Water cooling
