Bohn BN-LOPTB - Physical Data

11
The standard design for the Bohn Low Prole Evaporator incorporates a hot gas loop in the drain pan. Utilizing a hot gas
loop is ideal for hot gas defrost applications where high temperature gas can be maintained to defrost both the evaporator
drain pan and coil.
For applications where cooler (lower) temperature hot gas is used for defrosting, Bohn oers optional electric heater
elements in the drain pan to ensure quick and ecient defrost of the drain pan allowing condensate to drain quickly, saving
the hot gas for ecient evaporator coil defrost.
If the optional electric heating element drain pan is preferred, please specify when ordering, there is no additional charge.
Physical Data
Model HGT Hot Gas Defrost
Model
No. of
Fans
Connections (in.)
Approx.
Net Wt.
Coil
Inlet
ODF
Suction
ID
External
Equalizer
OD
Drain
MPT
Side
Port
OD
Hot Gas
Pan Conns.
OD
lbs. kg
6 Fins Per Inch
HGT035 1 5/8 5/8 1/4 3/4 3/8 5/8 26 12
HGT040 1 5/8 5/8 1/4 3/4 3/8 5/8 28 13
HGT047 1 5/8 5/8 1/4 3/4 3/8 5/8 31 15
HGT065 2 5/8 5/8 1/4 3/4 3/8 5/8 45 21
HGT075 2 5/8 7/8 1/4 3/4 3/8 5/8 47 22
HGT090 2 7/8 7/8 1/4 3/4 3/8 5/8 50 23
HGT120 3 7/8 7/8 1/4 3/4 3/8 5/8 62 29
HGT140 3 7/8 7/8 1/4 3/4 3/8 5/8 64 30
HGT160 4 7/8 1-1/8 1/4 3/4 3/8 5/8 83 38
HGT180 4 1-1/8 1-1/8 1/4 3/4 3/8 5/8 86 40
HGT200 5 1-1/8 1-1/8 1/4 3/4 3/8 5/8 103 47
HGT240 6 1-1/8 1-1/8 1/4 3/4 3/8 5/8 123 56
HGT280 6 1-1/8 1-1/8 1/4 3/4 3/8 5/8 126 57
4 Fins Per Inch
HGT041 1 5/8 5/8 1/4 3/4 3/8 5/8 30 14
HGT068 2 5/8 7/8 1/4 3/4 3/8 5/8 46 21
HGT080 2 5/8 7/8 1/4 3/4 3/8 5/8 49 23
HGT102 3 7/8 7/8 1/4 3/4 3/8 5/8 61 28
HGT136 4 7/8 1-1/8 1/4 3/4 3/8 5/8 82 38
HGT170 5 7/8 1-1/8 1/4 3/4 3/8 5/8 102 47
HGT204 6 7/8 1-1/8 1/4 3/4 3/8 5/8 122 56
HGT235 6 1-1/8 1-1/8 1/4 3/4 3/8 5/8 125 57
