6
Model LET/LLE Electric Defrost | 60 Hz
Model
Capacity Fan Data
10°F TD
-20°F SST
6°C TD
-29°C SST
No. CFM m
3
H
BTUH Watts
6 Fins Per Inch
LET035 3,500 1,025 1 700 1,189
LET040 4,000 1,170 1 700 1,189
LET047 4,700 1,380 1 650 1,104
LET065 6,500 1,900 2 1,400 2,379
LET075 7,500 2,200 2 1,300 2,209
LET090 9,000 2,640 2 1,300 2,209
LET120 12,000 3,520 3 2,100 3,568
LET140 14,000 4,100 3 1,950 3,313
LET160 16,000 4,690 4 2,600 4,418
LET180 18,000 5,280 4 2,600 4,418
LET200 20,000 5,860 5 3,250 5,522
LET240 24,000 7,030 6 3,900 6,627
LET280 28,000 8,200 6 3,900 6,627
4 Fins Per Inch
LLE041 4,100 1,200 1 690 1,172
LLE068 6,800 2,000 2 1,380 2,345
LLE080 8,000 2,340 2 1,380 2,345
LLE102 10,200 2,990 3 2,170 3,687
LLE136 13,600 3,990 4 2,760 4,690
LLE170 17,000 4,980 5 3,450 5,862
LLE204 20,400 5,980 6 4,140 7,035
LLE235 23,500 6,880 6 4,140 7,035
Performance Data
Model LET/LLE Electric Defrost | 50 Hz
†
Model
Capacity Fan Data
10°F TD
-20°F SST
6°C TD
-29°C SST
No. CFM m
3
H
BTUH Watts
6 Fins Per Inch
LET035 3,325 974 1 630 1,070
LET040 3,800 1,113 1 630 1,070
LET047 4,465 1,308 1 586 995
LET065 6,175 1,809 2 1,260 2,142
LET075 7,125 2,087 2 1,170 1,989
LET090 8,550 2,504 2 1,170 1,989
LET120 11,400 3,339 3 1,891 3,213
LET140 13,300 3,896 3 1,756 2,984
LET160 15,200 4,452 4 2,341 3,978
LET180 17,100 5,009 4 2,341 3,978
LET200 19,000 5,565 5 2,927 4,973
LET240 22,800 6,678 6 3,512 5,967
LET280 26,600 7,791 6 3,512 5,967
4 Fins Per Inch
LLE041 3,895 1,141 1 621 1,056
LLE068 6,460 1,892 2 1,243 2,111
LLE080 7,600 2,226 2 1,243 2,111
LLE102 9,690 2,838 3 1,954 3,320
LLE136 12,920 3,784 4 2,485 4,223
LLE170 16,150 4,731 5 3,107 5,279
LLE204 19,380 5,677 6 3,728 6,334
LLE235 22,325 6,539 6 3,728 6,334
†
For EC motors, use 60 Hz capacity and airflow values (Units with EC motors operating at 50 Hz
will not see a reduction in performance due to the electronic control of the motor)
Capacity Correction Factors For
Electric and Hot Gas Defrost Units
Saturated Suction
Temperature °F
+20 -10 -20 -30
Saturated Suction
Temperature °C
-7 -23 -29 -34
Multiply Capacity
By
1.15 1.04 1.00 0.90
To Next Page
