Installation manual BMG for Creality CR-10 V1.0 3
● Rotate the printer so you can
access the rear side.
● Disconnect the Bowden tube
from the extruder by pressing the
top collar down and pulling the
tube out at the same time
● Loosen and remove the M3
screws that holds the extruder
and motor attached to the
bracket.
Also disconnect the stepper
motor cable.
● Extruder and motor removed.
