Boneco S450 Service Manual

28. November 2016 / 4
Technical Data
Performance rating
Mains voltage
USA only with particular heater
220-230V / 50Hz
120V / 60Hz
Power consumption( Stufe I / II / III ) 160W / 360W / 480W
Power consumption ( Standby) 0.5W
Humidity output up to* 160 / 420 / 550 g/h
Suitable for rooms up to 60m
2
/ 150m
3
Capacity 7 liter
Operating noise level < 35 db(A)
Dimensions / Weight
Dimension (appliance) 355 x 240 x 334 mm
Overall dimension (singlebox) 403 x 282 x 399 mm
Weight (empty) 4.50 kg
* In the ECON-Mode:
Humidity output up to:160 / 420 g/h

Boneco S450 Specifications

General

Noise level	35 dB
Auto power off	Yes
Water tank capacity	7 L
Evaporation technology	Steam
Air purification capability	No
Suitable for room area up to	60 m²
Suitable for room volume up to	150 m³
Product color	Black, White
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz

Weight and Dimensions

Depth	240 mm
Width	355 mm
Height	334 mm
Weight	4500 g
