Boneco S450 Service Manual

28. November 2016 / 7
Steamer S450
Remove the pipe cover Remove the top cover Take the water tank out. Take the steam pipe out.
team pipe, watertank, pipe
cover, top cover.
Turn the appliance upside
down.
Clamp a thin plastic sheet
between side panel and
bottom.
Dismount instructions
Slide with the plastic-sheet
along the side panel until it‘s
removable
Remove the left and right side
panel.

Boneco S450 Specifications

General

Noise level	35 dB
Auto power off	Yes
Water tank capacity	7 L
Evaporation technology	Steam
Air purification capability	No
Suitable for room area up to	60 m²
Suitable for room volume up to	150 m³
Product color	Black, White
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz

Weight and Dimensions

Depth	240 mm
Width	355 mm
Height	334 mm
Weight	4500 g
