Boneco S450 Service Manual

28. November 2016 / 8
Dismount instructions
Lift the holder slightly with a
screwdriver.
Remove the bottom.
View from above.
Remove the print, float switch
and fan.
Remove the cable protection
cover.
Display panel, print cover,
print, float switch, fan and
humidity sensor
loose the screws and
remove the heater.
CAUTION: Put the fan-cable
at the assembling in it‘s
forseen port

Boneco S450 Specifications

General

Noise level	35 dB
Auto power off	Yes
Water tank capacity	7 L
Evaporation technology	Steam
Air purification capability	No
Suitable for room area up to	60 m²
Suitable for room volume up to	150 m³
Product color	Black, White
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz

Weight and Dimensions

Depth	240 mm
Width	355 mm
Height	334 mm
Weight	4500 g
