Boneco W200 User Manual

25
en
CLEANING THE APPLIANCE
5. Remove the AW200 evaporator mat from the
drum.
6. Clean the water base and the drum either by
hand or in the dish washer at a max. temperature
of 50 °C.
7. Put the appliance back together by following the
steps in reverse order.
DISASSEMBLY AND CLEANING
1. Take o the upper part of the BONECO appliance.
2. Remove the drum with the AW200 evaporator
mat.
3. Take out the A7017 Ionic Silver Stick®.
4. Rotate both drum discs to loosen. In doing so, ob
-
serve the markings on the outer side of the disc.

Boneco W200 Specifications

General

Type	Air Washer
Dimensions	280 x 280 x 412 mm
Room Size Coverage	50 m²
Weight	4.9 kg
Operating Modes	2
Humidification Output	300 g/h
