OVERVIEW AND PART NAMES
1 On/O , output level
2 Fan
3 Cover/air inlet
4 Fragrance container /
Key for the cover*
5 Drum*
6 AW200 Evaporator mat**
7 Air outlet
8 Power cable
9 A7017 Ionic Silver Stick®
10 Water base*
* Washable in the dishwasher
up to 50°C
** Washable in the washing machine
up to 40°C
1
2
3 4 5 6
87 9 10
