Bonex aquaProp - Technical Data

aquaProp–SCOOTER
Instruction for use
Version : SG 2015-11 Page | 6
6. Technical Data
(*) The speed and driving time depends on the configuration of the diver, underwater
position, as well as the water temperature.
Modell
aquaProp
aquaProp
L
Dimensions: Ø 140/230 - L 570 mm Ø 140/230 - L 570 mm
Battery: 12 V – NiMh Battery 12 V – LiMn Akku
Weight: 6 kg 6 kg
Battery weight: 2,5 kg 2,5 kg
Operating depth: 80 m 80 m
Operating temp.: 4° - 30°C 4° - 30°C
Runtime step 1: 75 min* 200 min*
Runtime step 2: 50min* 120min*
Thrust max.: 140 N 140 N
Speed step 1: 38 m/min* 38 m/min*
Speed step 2: 50 m/min* 50 m/min*
Trim: neutral / slightly positive neutral / slightly positive
Charger:
230V-50Hz
110V-60Hz
230V-50Hz
110V-60Hz
Charging time: 9 hrs. 6 Std.
