Bonex ECOS - Spare Parts

BONEX-SCOOTER
Instruction for use
Version: 2016_08 Page 31
13.2 Spare parts
Pos.
Count
Name
Order n
um
b
er
2 1 Zinc anode 11-11009
8 1 Locking screw 11-11007
10 1 Propeller 11-13003 / -13007
28 1 Pressure disc 19-41006
101 1 Synchronous motor; 48V
102 1 Sliding ring seal; D=12mm
103 1 Grooved ball bearing; D=15mm
104 2 Reed sensor; D=6mm
105 2 Magnet; D=6mm;
106 1 Speed governor;
107 1 Mainswitch unit;
108 2 Power plug; 4-pole
111 1 Control plug; 12-pole
114 1 Pressure piece M8
115 1 Arm spring 11-31004
118 1 Locating pin; D=3mm;
119 1 Locating pin; D=5mm;
120 1 Eyebolt; M=6;
121 8 Polyamid washers; M=6mm
122-1 2 O-ring; D=190 x 5,3mm
122-2 2 O-ring; D=190 x 4,0mm
123 4 O-ring; D=12 x 2,5mm
124 4 O-ring; D=12 x 2,5mm
125 4 O-ring; D=6 x 1,5mm
126 12 O-ring; D=25 x 3,0mm
127 1 O-ring; D=18 x 3,0mm
128 1 O-ring; D=15 x 3,0mm
131 4 Stop ring; D=15mm
