Strap and ring
Rope and hooks
Open strap
and eye-bolts
Shackle
(for use with strap)
Safety hook
(for use with rope)
Eye-bolt
Lift manually
(weight ≤ 15 kg)
Lift according
to drawing A
Lift according
to drawing B
Maximum tilt permitted during
movement: 15°
W Series
W 63 WR 63 M
M
W 75 WR 75
A - B
W 86 WR 86
W 110 WR 110
B A - B
