2.2. PART NUMBER BREAKDOWN
Figure 2-1: Example of Part Number Breakdown
BASE MODEL NUMBER
The base model number for all Automatic Capacitor Formers is M3628ACF.
MAX OUTPUT VOLTAGE RATING
The max output Voltage rating indicates the maximum DC output voltage the unit can
supply. The max output voltage is indicated by a code letter.
Table 2-1: Max Output Voltage
RATING CODE
VOLTAGES
(DC VOLTAGE OUTPUT)
Y
1000VDC out
MAX OUTPUT CURRENT RATING
The max output current rating indicates the maximum DC current the unit can supply
at its maximum voltage.
INPUT VOLTAGE
A three digit code represents the input voltage that should be used.
Table 2-2: Input Voltage
RATING CODE
INPUT VOLTAGE
120
110-120 VAC
240
220-240 VAC
M3628ACF
Y
01
BASE MODEL NUMBER
MAX OUTPUT VOLTAGE
MAX OUTPUT CURRENT
INPUT VOLTAGE
120
