4.2.2.1.1.1. SET FINAL VOLTAGE
From this screen the user may set the final voltage they wish
to charge the load to. The right and left buttons control which
digit is presently being edited, and the up and down buttons
increment or decrement that digit. Pressing Enter will exit this
screen and save the voltage.
4.2.2.1.1.2. SET STEP VOLTAGE
From this screen the user may set the voltage step by which
the load will approach the final voltage. The right and left
buttons control which digit is presently being edited, and the
up and down buttons increment or decrement that digit.
Pressing Enter will exit this screen and save the voltage.
4.2.2.1.1.3. SET CURRENT
From this screen the user may set the maximum current with
which they wish to charge the load. The right and left buttons
control which digit is presently being edited, and the up and
down buttons increment or decrement that digit. Pressing
Enter will exit this screen and save the current.
4.2.2.1.1.4. SET STEP HOLD TIME
From this screen the user may set the number of minutes
each step voltage will be held. The right and left buttons
control which digit is presently being edited, and the up and
down buttons increment or decrement that digit. Pressing
Enter will exit this screen and save the hold time.
The maximum step time is 999 minutes or about 16 hours and
39 min.
4.2.2.1.1.5. SET FINAL HOLD TIME
From this screen the user may set the number of seconds the
final voltage will be held. The right and left buttons control
which digit is presently being edited, and the up and down
buttons increment or decrement that digit. Pressing Enter will
exit this screen and save the hold time.
The maximum final hold time is 999 minutes or about 16
hours and 39 min.
4.2.2.1.1.6. CHARGE CONFIRM
At this screen the user is asked to confirm the charge voltage
and current, and begin charging the output.
4.2.2.1.1.6.1. CHARGING
This screen displays the present output voltage and
current. It transitions to the "Discharging" screen
(4.2.2.1.3.1.) when the output voltage reaches the
set point and is held for the specified number of
seconds. Charging may be aborted by pressing the
Cancel button.
