6
50mm
8mm
45mm
3.8mm
Wood Stud Wall
Concrete & Brick Wall
Diagram 5a Diagram 5b
Diagram 5e
Wall
Diagram 5c
Diagram 5d
If your TV is located nearby the wall as the Diagram 5a, then a steel wire can be attached for added security. Attaching
the two ends of steel wire to the top two holes on the back of TV, shown in Diagram 5b.
Attaching the another end of steel wire to the wall according to your wall type, shown in Diagram 5c, 5d and 5e.
