BDVM-8455MPBTV
- 47 -
SPECIFICATIONS
GENERAL
Supply Voltage
14.4V DC (11-16V allowed)
Load Impedance
4Ω per channel
Max Power Output
50W x 4
Bass 100Hz
≥ 10dB
Treble 10KHz
≥ 10dB
Dimensions (approx.)
183 x 188 x 60 mm (d/w/h)
Mounting (approx.)
160 x 178 x 50 mm (d/w/h)
FM TUNER
Frequency Range
87.5 – 108 MHz (Europe/Asia)
87.5 – 107.9 MHz (USA)
IF
10.7 MHz
Usable Sensitivity
≤ 15dBuV
Stereo Separation
≥ 26dB (1 KHz)
Frequency Response
100-20000Hz
AM TUNER
Frequency Range
531 - 1602 KHz (Asia)
522 - 1620 KHz (Europe)
530 - 1710 KHz (USA)
IF
450 KHz
Usable Sensitivity
≤ 40dBuV
TV TUNER (Optional)
Frequency Range
NTSC : 55.25 MHz~855.25MHz
PAL: 48.25 MHz~855.25MHz
DVD PLAYER
Signal-to-noise Ratio
≥ 85dB (1 KHz)
Distortion
≤ 0.5%
MONITOR
Resolution
432 (w) x 240 (H) (RGB)
Brightness
400 cd/m
2
Contrast
400:1
NOTE:
Specifications and design are subject to modification without notice due to
improvement in technology.
